How To Choose a Lithium Battery for RVs

2021-10-14

12V100Ah Lithium Batteries For RV


Superpack's RV lithium batteries are becoming much more popular with RV ers as they become safer, more efficient,  you can store more energy and access more power in lithium-ion batteries. because they have a more dense and efficient energy storage system, which translates to more power available to you and the electrical systems in your RV.

While some travelers depend on their RVs every day, many travelers use RVs on a seasonal basis, so it is important to use a battery that will operate even after being idle during the offseason.


Superpack's 12v100Ah lithium batteries can be use it as an alternative power source at outdoor or have it ready in case of an emergency power outage. It can be used to charge a number of appliances and electronics. Whether you're going on a family camping trip or preparing for a drive across the country, a quality battery for your recreational vehicle is essential. A camper battery must be able to power your non-engine systems—such as lights, water pump, furnace and other appliances—for extended periods of time.


Lithium batteries are a drop in replacement for AGM, SLA, or traditional lead acid batteries

Superpack's Lithium Battery In addition to being very lightweight, they also come in a range of different, highly compact,Lithium batteries do cost more when initially purchased. It’s also true that they last so much longer than lead-acid batteries, they can actually be less expensive in the long run. A single lithium battery typically lasts at least ten times longer than its lead-acid counterpart. With lithium batteries, charging is four times faster than SLA. The faster charging means there is more time the battery is in use, and therefore requires less batteries. They also recover quickly after an event (like in a backup or standby application). As a bonus, there is no need to keep lithium on a float charge for storage.So, if you intend to keep your rig for a reasonable length of time, the investment will almost certainly pay off.


Name lifepo4 low temperature charging
Model SPF12V100-DLB
Rated Voltage 12.8 V
Rated Capacity 100 Ah
Energy 1280Wh
Maximum Charge Current 100A
Self Discharge <3% / Month
Resistance ≤10 mΩ @ 50% SOC
Max. Continues Discharge Current 100A
Peak Discharge current 300 A (3s)
Approx. Dimension L*W*H 318 x 175 x 190 mm
Approx. Dimension L*W*H 355 x 175 x 190 mm
Weight(Approx.) 27.8 lbs (12.6 kg)
Weight(Approx.) 28.2 lbs (12.8 kg)
Terminal Torque 80 ~ 100 in-lbs (9 ~ 11 N-m)
Heating Temperature Range -4 to 41 ºF (-20 to 5 ºC)
Heating Time Approximately 1 hour @ 7.5 A
BMS Heating Foil Cut-Off 158 ºF (70 ºC)
Housing material ABS
Enclosure Protection IP65


More 12V Series LiFePO4 battery

Model

Nominal

Voltage

(V)

Nominal

Capacity

(Ah)

Max discharge

current (A)

Dimension

(mm)

Dimension

(in)

BCI/DIN

size

Approx.Weight

(Kg)

Weight

(lbs)

Terminal

Terminal Layout


Batteries

in series


SPF12V100-LB

12.8

100

100

329*172*223

13.0*6.8*8.8

31

12.6

27.8

T11(M8)

A

Consult
Superpack
for insight

SPF12V100-DLB

12.8

100

100

335*174*191

13.2*6.8*7.5


12.8

28.2

DIN

B

SPF12V200-LB

12.8

200

100

520*268*228

20.5*10.6*9

8D

25.8

56.9

T11(M8)

C

SPF12V260-LB

12.8

260

100

520*268*228

20.5*10.6*9

8D

32.0

70.5

T11(M8)

C

SPF12V300-LB

12.8

300

100

520*268*228

20.5*10.6*9

8D

35.7

78.7

T11(M8)

C
