| Production Basic Information | Remark | |
| Standard charge |
0.2C constant current(CC) charge to 67.2Vthen constant voltage (CV) 67.2V charge till charge current decline to ≤0.05C |
Charge time :Approx 7h |
| Standard discharge | Constant current 0.2C，Cut-off voltage 10V | |
|
Maximum Charge Current |
10A | |
|
Maximum Continuous Discharge Current |
＜70A | |
|
Operation Temperature Range |
Charge: 0～45℃ |
60±25%R.H. 23 ± 5°C（ recommended） |
|
Discharge: -20～60℃（cell surface temperature≤80℃） |
||
|
Storage Temperature Range |
Less than 1 year : 0～25℃ |
60±25%R.H. at the shipment state |
| Less than 3 months:-5～35℃ | ||
| Approx. Weight | ≈9.2Kg | |
| Internal resistance | ≤70mΩ | 1KHz，AC |
| Dimension | L*W*H=（171*165*180mm）±1mm | |
| Terminals | Anderson SA120 | |
| IP Rating | IP56 |
