Home Solution Home Energy System Low Voltage Battery

Power wall 3Kwh 5Kwh LiFePO4 lithium battery for Home Energy Storage System

 5Kwh  Power wall Energy Storage System
 5Kwh  Power wall Energy Storage System
 5Kwh  Power wall Energy Storage System
 5Kwh  Power wall Energy Storage System

Power wall 3Kwh 5Kwh LiFePO4 lithium battery for Home Energy Storage System

Superpack 48v Energy Storage System is widely apply for home and business.

  • Brand:

    Superpack
  • Product Details

Power wall 3Kwh  5Kwh LiFePO4 lithium battery for Home Energy Storage System



Home Energy Storage System (HESS)



Superpack provides the most ideal lithium battery solution

Superpack 48v Energy Storage System is widely apply for home and business.

 Superpack 51.2V 100Ah LiFePO4 lithium battery solar energy storage system adopts the latest Home Energy Storage System (HESS) battery system. With rich experience and advanced techniques, it features fashionable design, high energy, high power density, long service life, and easy installation and expansion, all of which reflect the real requirements of the end users and the strongest technical capability.

 Superpack 51.2V 100Ah LiFePO4 lithium battery It is a kind of environmentally friendly backup power system.Compared with other products in the market now, this kind of product experiences a lower rate of capacity loss. With state-of-the-art power conversion and energy storage technologies, our energy storage system (ESS) offers high-efficiency power conditioning capabilities for demand management, power dispatch, renewable energy smoothing, etc. Our ESS can provide comprehensive energy storage for residential, commercial and utility applications. Our Li-ion battery portfolio covers cells, 48V modules, cabinets (indoor/outdoor) and containers, which offer customers excellent scalability and adaptability to a wide variety of requirements.



Features

• Fast Charge & Discharge Rates

• International standard 48V system.

• USB/RS485/Wi-Fi/GRS(option)
• 98% Efficiency Rate
Perfect protection function of BMS
• Modular, Scalable & Proven Performance
• Long life cycle, >6000 times at 80% DOD

• Easy to install

• Environmental friendly

 Perfect thermal design





Parameter

 Model  SPESS-3000B  SPESS-5000B
 Rated Voltage  51.2V  51.2V
 Operating Voltage  40-58.4V  40-58.4V
 Rated Capacity  60 Ah  100 Ah
 Energy  3.0KWh  5.0KWh
 Max. Continuous Charge Current  60A  100A
 Max. Continuous Discharge Current  80A  120A
 Charging temperature range  0-45℃  0-45℃
 Discharge temperature range  -10-60℃  -10-60℃
 Approx. Dimension L*W*H  793.7mm*562mm*138mm
Approx. Weight  48kg
Life  10 Years
Installation form  Wall-mounted
 Battery BMS protection function

  Overcharge/overdischarge/overtemperature/

overcurrent/short circuit

  Overcharge/overdischarge/overtemperature/

overcurrent/short circuit

Power charging
Cycles(80%DOD 25℃)

(170Vac~280Vac)±2%

(90Vac~280Vac)±2%

Solar panel input voltage

 Voltage ≤145V, current ≤60A, maximum power 4200W

AC output parameters
  Output voltage  AC220V  AC220V
 Maximum output power  Two output ports total: 3000W  Two output ports total: 5000W
 Peak output power   6000W/5S  10000W/5S
 Wave type   Sine wave  Sine wave
 Frequency   50Hz  50Hz
 Efficient   >95%
 LCD
 Display size  41*13mm
 Working power consumption  MAX8mA
 Standby power consumption  MAX0.5mA
 Sleep power consumption  MAX50uA



Product dimensions

Superpack 48V100Ah Energy storage wall size

Compatible with 48V DC Inverter

Inverter Brand Inverter Type Communication Application Installation
sunny island 6.0H     Powerwall Battery
Victron energy Multiplus 48V CAN On/off-grid* Powerwall / Rackmount Battery
deye SUN-SG01LP1 series CAN / RS485 On/off-grid* Powerwall / Rackmount Battery
SUN-SG03LP1 series CAN / RS485 On/off-grid* Powerwall / Rackmount Battery
growatt inverter SPH3000 - 6000  CAN  On/off-grid  Powerwall / Rackmount Battery
SPF2000 - 5000   RS485(9600)  On/off-grid  Powerwall / Rackmount Battery
GW-BP  CAN  On/off-grid  Powerwall / Rackmount Battery
SBP GW-ES  CAN  On/off-grid  Powerwall / Rackmount Battery
EM CAN  On/off-grid  Powerwall / Rackmount Battery
Xtender 48V serie CAN  On/off-grid  Powerwall / Rackmount Battery
Voltronic inverter Infinisolar series 48V RS485(9600) On/off-grid  Powerwall / Rackmount Battery
Axpert series 48V RS485(9600) On/off-grid  Powerwall / Rackmount Battery
solis inverter RHI series CAN  On/off-grid  Powerwall / Rackmount Battery
Luxpower LXP Hybrid 6K/8K CAN  On/off-grid  Powerwall / Rackmount Battery
Invt inverter BD series CAN  On/off-grid  Powerwall / Rackmount Battery
Sermatec SMT-5K-TL-LV CAN  On/off-grid  Powerwall / Rackmount Battery
Conext XW Pro series CAN    Debugging in progress
SOFAR HYD series RS485(115200)/CAN   Debugging in progress
Phocos Any-grid PSW-H-5kW-230/48V RS485(9600)   Debugging in progress
SH5K CAN   Debugging in progress
BK-BP Series CAN   Debugging in progress
