• Ultra-high energy density, light weight and compact design.
• Incorporates a stable and high-performance IC solution within the built-in smart BMS.
• Versatile communication options: I2C, HDQ, UART and SMbus.
• Fast charge within 3 hours.
• The capacity is ≥85% at 0.2C discharge in low temperature applications of -40℃
• Support hot swapping.
• Integrated with a charging management circuit, compatible with QC3.0, PD3.0 for versatile DC-DC charging at 5V, 9V, 12V, etc.
• Widely used in B-ultrasound, Vital Signs Monitor, ECG, Defibrillator, Ventilator, Syringe Pump, Oximeter, Anesthesia, Pulmonary Function, etc.
• Comply with IEC 60601-1:2012 and passed IEC62133, CE61000, UL1642, UN38.3.
|
Model |
NCM10.8V2.2-LT |
NCM14.4V2.6-ST |
NCM14.4V5.2-ST |
NCM14.4V5.2-LT |
NCM21.6V3.4-SM |
|
Nominal Voltage |
10.8V |
14.4V |
14.4V |
14.4V |
21.6V |
|
Nominal Capacity |
2200mAh (23.76Wh) |
2600mAh (37.44Wh) |
5200mAh (74.88Wh) |
5200mAh (74.88Wh) |
3400mAh (73.44Wh) |
|
Max. Continuous Discharge Current |
3A @20℃ |
4A @20℃ |
5A @20℃ |
5A @20℃ |
5A @20℃ |
|
Max. Charge Voltage |
12.6V |
16.8V |
16.8V |
16.8V |
25.2V |
|
Max Charging Current |
3A @20℃ |
4A @20℃ |
3A @20℃ |
3A @20℃ |
3A @20℃ |
|
Charge Temperature Range |
0~45℃ |
0~45℃ |
0~45℃ |
0~45℃ |
0~45℃ |
|
Discharge Temperature Range |
-40~55℃ |
-20~60℃ |
-20~60℃ |
-40~55℃ |
-20~60℃ |
|
Weight |
138g |
195g |
390g |
399g |
330g |
|
Dimensions (LxWxH) |
56x19x72mm |
38x21x138mm |
75x38x72mm |
150x20x72mm |
57x38x74mm |
|
Communication |
N/A |
N/A |
N/A |
N/A |
SMbus |
|
Application |
Infusion Pump |
Patient Monitors |
ECG Mornitor |
Oxygen Generator/ Vital Signs Mornitor |
Respirator Machine |
|
Cycle Life |
≥ 500 cycles |
||||
|
Battery Type |
Li-Ion (NCM) |
||||
|
Housing |
PVC |
||||
|
Certification |
CE, CB-IEC62133, UL1642, UN38.3 |
||||
