Specification
Item |
Specification |
Remarks |
Nominal Capacity |
5000mAh |
@0.2C discharge (1000mA), 2.75V cut off |
Typical Capacity |
4900mAh |
@0.2C discharge (1000mA), 2.75V cut off |
Minimum Energy |
18.5Wh |
@0.2C discharge (1000mA), 2.75V cut off |
Nominal Voltage |
3.6V |
|
Charge Voltage |
4.20±0.02V |
|
Charge Mode |
CC/CV |
|
Charge |
Standard charge : 0.2C (1000mA) |
Charge at 1000mA to 4.20V, then 4.20V (constant voltage) until the charge current is less than 100mA (0.02C) cut off |
Rapid charge : 1.0C (5000mA) |
Charge at 5000mA charge to 4.20V, then 4.20V (constant voltage) until the charge current is less than 100mA (0.02C), cut off. |
|
Discharge |
Standard Discharge : 0.2C (1000mA) |
Constant Current 0.2C5A end Voltage 2.75V |
Rapid Discharge : 1.0C (5000mA) |
Constant Current 1C5A end Voltage 2.75V |
|
Max. Charge Current |
1C (5000mA) |
1.0C(45℃ ≥T≥ 10℃ ) |
Cont. Discharge Current |
1C (5000mA) to 2.75V |
0.5C(50℃ ≥ T≥ 45℃ ) |
Max. Discharge Current |
2C (10000mA) |
5C(45℃ ≥T≥5℃ ) |
Inner Resistance |
≤35mΩ |
1kHz AC Method |
Weight (Approx.) |
95±2g |
|
Dimensions |
Diameter: 26.5±0.5mm |
Weighing 300gf at 25 ±2℃ |
Height: 65.5±0.5mm |
||
Cycle Life |
≤500 times |
@0.2C discharge, 100% DOD |
Operating Temperature |
Charge: 0 ~ 45℃ |
|
Discharge : -20 ~60℃ |
||
Storage Temperature |
1 year : 10~20℃ |
At half charged state |
3 months : -0~25℃ |
||
1 month : -20~30℃ |
||
Storage Humidity |
5%≤RH≤85% |
|
