New Products

288V52Ah ESS Energy Storage System

Six 48V52AH LiFePO4 Battery module to be 288V battery energy storage system
  • Brand:

    Superpack
Product Detail

Superpack system is a powerful and scalable Lithium Iron Phosphate Energy Storage System for a wide variety of energy storage applications (heavy traction, stationary, industry, UPS, telecommunications, weak and off-grid, self-consumption systems, smart-grid, etc.)

Superpack 48V52Ah Energy storage battery modules are fitted in a 19 inches cabinet for space saving and increased energy density. Standard 19 inches cabinet format allow to be fully compatible with some professional application such as back-up telecom batteries, UPS systems, sub-station, and some industrial systems.

Superpack Systems has rigorously selected and tested best-in-class Lithium Iron Phosphate cells that are assembled in this product, in order to provide high lifespan and performance.
Lithium Iron Phosphate (LFP) is currently the best solution for storing energy, because of its durability, its high safety and its technical superiority compared to other technologies on the market.

About Superpack Energy Solution
Superpack Energy Solution is a leading supplier of advanced lithium-ion batteries for electric vehicles (EVs), mobile and IT applications, and Energy storage systems (ESS).


Cell Specification

Items

General Parameter

Cell type

LiFePO4 IFR26700 4.0AH

Model

26.4*71mm

Rated Voltage

3.2V

Operating voltage range

2.0V-3.65V

Rated capacity

4.0AH

Batteries weight

93g

Energy

140Wh/Kg

Internal resistance(mΩ)

14±2mΩ

Max. Continuous Charge Current@25℃

4A

Max. Continuous Discharge Current@25℃

8A

Max. Continuous Charge Current@25℃

4A

Operating Temperature

Charge:0~50℃
Discharge:-20~60℃


Moduel Specification

Items

Specification

Rated system voltage

48V52Ah

Moduel Dimension

3U (435*451*132mm)

Nominal Voltage

48V

Operating Voltage Range

42V-54V

Nominal Capacity

<3.5%

Nominal Capacity

52A

Weight

28.5Kg

Energy Density

87Wh/Kg

ACIR

35mΩ

Max. Continuous Charge Current@25℃

52A

Max. Continuous Discharge Current@25℃

52A

Operating Temperature

Charge:0~50℃
Discharge:-20~60℃

IP Protection grade

IP54

BMS Specification

Items

Specification

Nominal Capacity

52Ah

Nominal Voltage

288V

Charging Cut-off Voltage

324V

Charging method

Constant Current with limited Voltage- Constant Voltage with limited Current)

Max. Continuous Charge Current@25℃

52A

Max. Continuous Discharge Current@25℃

52A

Max Discharge Power @25℃

14.9KW

Peak Discharge Power @25℃,100ms

28.8KW

Discharge Cut-off Voltage

52A

Discharge Cut-off Voltage

252V

Weight

≈180Kg

Internal resistance

250mΩ

Communication mode

RS485


Size

  48V52Ah Home energy storage battery size diagram

Inverters for HV series battery

growatt inverter SPH4000 - 10000TL3 CAN On/off-grid Powerwall Battery
Sermatec SMT-10K-TL-TH CAN On/off-grid Powerwall Battery
GW-ET CAN On-grid Powerwall Battery
Phocos Any-grid PSW-H-5kW-230/48V RS485(9600) On-grid Debugging in progress
